The Ripley is our snappy, flickable, playful, fast, lightweight, and versatile 29” trail bike.

Its combination of modern geometry, a stiff lightweight carbon chassis, and 120mm of ultra efficient dw-link travel, means it’s equally happy popping off bonus lines as it is crushing all day epics.

With its well balanced modern geometry, the Ripley is ready for any adventure. The long front end, slack head angle, and short rear end gives you the confidence to try new lines, while the steep seat tube angle and shorter offset fork makes it easy to maneuver technical climbs and flowy singletrack.

The Ripley V4S features a new UDH dérailleur for maximum future compatibility and moves to a 55mm chain line. The wider chain line allows for a stiffer chainstay.

Sometimes, shorter is better. Instead of the typical 51mm offset, the new Ripley uses a 44mm offset. This gives you the stability of a slacker head angle, while retaining the BMX like feel of, well, a Ripley.

We pioneered the wide rim revolution a few years ago and inspired a new crop of wider 2.4” — 2.6” tires. When paired together, this combo can be run at ultra low pressures that produce elbow-dragging cornering traction without sacrificing speed.

Model Version

Ripley V4S

Frame Material
Carbon Fibre Monocoque

Fork
Fox Factory Series, Float 34, 130mm, 44mm offset, 29”, 110x15mm

Shock
Fox Float Factory DPS with EVOL, 190x45

S/M: Light Tune, L/XL: Standard Tune

Wheels
Blackbird Send Alloy (Send I front, Send II rear) / 29" / Ibis Hubs

Tires
Maxxis DHR2 29" x 2.4" Exo TR (front), Maxxis Dissector 29" x 2.4" Exo TR (rear)

Brakes
Shimano XT M8100

Brake Rotors
Shimano SM-RT86 180

Cranks
Shimano XT M8120 24mm spindle, 30t Alloy Ring

S/M: 170mm, L/XL: 175mm

Bottom Bracket
Shimano XT MT800

Rear Derailleur
Shimano XT M8100 Shadow Plus 12 speed

Shift Levers
Shimano XT M8100 12 speed

Cassette
Shimano XT 10-51

Chain
Shimano XT M8100 12 speed

Headset
Cane Creek 40 ZS44/ZS56

Grips
Lizard Skin Charger Evo

Handlebar
Ibis Carbon Hi Fi, 31.8mm, 800mm

Stem
Industry Nine A318

S/M: 40mm, L/XL: 50mm

Seatpost
Bike Yoke Revive Dropper

S: 125mm, M: 160mm, L: 185mm, XL: 213mm. Note there is a 250lb rider weight limit on this post.

Saddle
WTB Silverado

* Specifications are subject to change without notice
